EASY, PRACTICAL AND UNEXPENSIVE BAGGING WITH SPEEDBAG EV

Ideal for wrapping and mailing newspapers and magazines, catalogues and wholesale publications, manuals and any commercial printed materials,  in single or multipack. Half-automatic, easy to use: the only thing the operator has to do is simply to feed products vertically into the metal “throat of a shirt“ in fact the whole machine cycle is fully automatical. The bag width is adjusted accorging the product  width through the metal “throat“, a photocell senses the top and the bottom of the product and switches on the film-unwinding device so that a bag is formed around the product. The bag is then sealed and cut accordingto the product length. Compact and really unexpensive machine which is essential for do-it-by-yourself maiing.

download attachments

  • Vertical feeding
  • Two way of working: Manual or Automatic with unit-counter
  • Digital control panel
  • Independent sealing-bars; sealing-time and temperature controlled by PCB
  • Minimum bag dimensions: 50 x 140 mm; thickness 1mm
  • Maximum bag dimensions: up to 350 x 270 mm; thickness 12 mm
  • Motorized film-unwinding
  • Wide table-top for products
  • Motorized output conveyor belt on request
  • The machine works with transparent or printed LLDPE (thickness 15 ÷ 40)
Machine made according to CE rules.

SPECIFICATIONS  – SPEED BAG EV

  • Power supply: 230V – 50/60 Hz – 1 Ph
  • Power required: 1 kW
  • Overall machine dimensions L x W x H: 930 x 640 x 1150 mm
  • Weight: 100 Kg
  • Min. wrapping size L x W x H: 50 x 140 x 1 mm
  • Max wrapping size L x W x H: 350 x 270 x 12 mm
  • Film roll width: 600 mm
  • Output up to: 1200 pcs/h

Notes: Technical data subject to variations without prior notice
Output depends on the operator and the type of the package
