ECOFARD AOL LINE

heat-shrinking sleeve-wrapping systems

AUTOMATIC SLEEVE-WRAPPING WITH LATERAL FEEDING

Fully automatic sleeve-wrapper with lateral feeding for “multipackage” (several products wrapped up together on several lines) without an operator.

Practical high-speed sleeve-wrapping machine able to package a wide range of products (bottles, vases, jars, pots, cans, phials, cases etc) and to shelter boxes integrating and/or replacing the use of carton boxes at end-of-line with great management advantages.

The machine is compact and consists in a sealer and a tunnel.

It works in a very simple way: a motorized in-feed belt conveyor, situated at 90 ° from the sealing bar, drives the products from the loading area towards the sealing area. Then a transversal sealing-bar (that has a pneumatic movement and temperature is electronically controlled) cuts and seals the film. At this point the wrapped product enters the tunnel for shrinking.

The models available are 500, 700, 900 and 1250.

Ideal for high outputs.

download attachments



  • LATERAL automatic feeding with driving system
  • Pneumatic pusher for automatic feeding of multipack into the sealing area
  • Sealing time electronically adjustable
  • Sealing-bar with two sealing blades and one teflon-coated cutting blade controlled by electronic thermo-regulator ; pneumatic movement
  • In case of any obstacle presence safety arrest of the sealing blades
  • Product detected by a system of photo-eyes
  • The wrapped product stays on a plate behind the sealing area till the outcoming wrapped product pushes it onto the tunnel belt conveyor that is always running
  • Protections of moving parts with aluminum, polycarbonate and/or perforated sheet panels
  • In-line in-feed belt conveyor running with fixed speed
  • Tunnel steel zinc-coated mesh belt conveyor
  • Tunnel air heating by finned resistances controlled by an electronic thermo-regulator
  • Closed and forced air circulation with air flow adjustable by flaps in order to have the best shrinking
  • Cooling fan at the tunnel exit included
  • Internal tunnel parts made by steel zinc-coated
  • External powder painting
  • Double-rolls system with motorized top and bottom film-unwinding



OPTIONS:

  • Customized in-feed belt conveyor
  • Vertical rollers to compress the film excess at the tunnel exit
  • Customized tunnel and sealing-bar height
  • After-sealing-bar top-clamp to block unstable products
  • Frequency AC engine controller for tunnel belt conveyor
  • Inverter to adjust the control speed on the tunnel and/or sealing conveyor belt
  • Discharging idle roller conveyor
  • Extended tunnel carpet at the exit to allow greater cooling of the film



The machines works with single-wounded (flat) LLDPE

Machine made according to CE rules.



ECOFARD 500 AOL

  • Sealing Bar: lenght 500 x H 240 mm pneumatically working controlled by photo-eye
  • Roll sizes: 250 x 480 mm
  • Max tunnel entrance: 480 X H 340 x 870 mm lenght
  • Output: Up to 12 pz/min
  • Power supply: 3 Ph + N + T | 220/380 V 8 KW
  • Motorized film unwinder: Superior roll – Inferior roll optional



ECOFARD 700 AOL

  • Sealing Bar: lenght 500 x H 380  mm pneumatically working controlled by photo-eye
  • Roll sizes: 250 x 680 mm
  • Max tunnel entrance: 700 X H 410 x 1300 mm lenght
  • Output: Up to 12 pz/min
  • Power supply: 3 Ph + N + T | 220/380 V 17 KW
  • Motorized film unwinder: Superior roll – Inferior roll optional



ECOFARD 900 AOL

  • Sealing Bar: lenght 900 x H 410 mm pneumatically working controlled by photo-eye
  • Roll sizes: 250 x 880 mm
  • Max tunnel entrance: 900 X H 500 x 1400 mm lenght
  • Output: Up to 12 pz/min
  • Power supply: 3 Ph + N + T | 220/380 V 24 KW
  • Motorized film unwinder: Superior roll – Inferior roll
