THE SMARTEST AND MOST INNOVATIVE PACKAGING SOLUTIONS

UNIQUE BF EV

flowpack packaging system

THE MOST VERSATILE AND SMARTEST PACKAGING MACHINE IN THE WORLD

UNIQUE is a great invention, an atypical flow-pack machine with high potentialities and where the conformer, the driving rollers, the sealing rollers and the crimp and seal system all form a single rotating group that allows to use the machine and to load products in different horizontal, diagonal or even vertical positions, providing endless range of uses and applications. The exclusive features are making Unique ideal for an endless number of applications for the agri-food packing in particular:

  • Baked products – bread – confectionery – pasta – pizza – focaccia – frozen foods – vegetable and fruits of all kinds, poultry, salami, white meats, cheese… to be single or multi packed, with or without a tray, and so on.
  • Technical articles, hobby items, home accessories, households…UNIQUE probably represents the only and sole solution for packing products with a wide difference in the length (profiles and segments in wood, metal, plastic, electrical conduits, tubes, coils …) without having to re-parameter or to re-adjust the machine.

UNIQUE is a system completely synchronized with the operator. The loading of the product automatically activates the film unwinding and its forward moving and bagging. It is not the operator to run after the machine, but the machine adapting itself to the operator.

UNIQUE can be integrated with feeding and loading systems, like motorized belts conveyors or simple gravity sliding plates specifically realized on the basis of the products to be packed, to implement performances and functionality. UNIQUE is therefore transforming itself into a real automatic production unit. UNIQUE can also be used for the packing of the multiple pieces, and in this case the working procedure is activated each time by the operator.

UNIQUE is equipped with a PLC operating system with a software of latest generation developed by the R&D ITALDIBIPACK with a “touch screen” control panel which allows the most simple and fast setting of the different working parameters such as the speed, the sealing temperatures, the length of the bags, and so on.

download attachments

TECHNICAL CHARACTERISTICS

  • Double pair of wheels (film drive and longitudinal seal)
  • Transversal sealing by “crimp and seal” jaws with vertical closure
  • Adjustable conformer to facilitate and expedite format changes
  • Feeding speed (equivalent to the packing speed) adjustable through the PLC
  • Temperature of the “crimp and seal” jaws and of the sealing rollers electronically controlled by the PLC

OPTIONALS

  • Cross reading photo-eye for the automatic detection of the product length
  • Photo-eye for films with a registered print
  • Special transversal “crimp and seal” jaws for “EURO slot” function
  • Nozzle for the gas/alcohol injection
  • Further options available on request, to satisfy the most different packing needs and requests

SPECIFICATIONS – UNIQUE BF EV

  • Power supply: 240V – 1ph – 50 Hz
  • Maximum power required: 3 kW
  • Machine dimensions L x W x H: 1000 x 1300 x 1500 mm
  • Machine weight: 300 kg
  • Minimum bag dimensions: 100 x 100 x 10 mm
  • Maximum bag dimensions: oo x 300 x 160 mm*
  • Maximum roll width: 700 mm
  • Output: 15/25** pcs/min

notes:* it is not possible to realize bags with the max W and the max Hsimultaneously.** Depending on the characteristics of the film and on the products dimensions.
